SDR-001Glasgow, Scotland

SIDRA Autonomous aircraft for GPS-denied environments.

Sensing, navigation and mission autonomy, built in Scotland.

Engineered in Scotland · UK
0%  Glen scanned

Reading the glen

The scan line moves up Glen Coe as you scroll. Behind it, the hillside turns into measured heights.

Contour interval  50 MGrid  1 km

The ground, measured

This is the glen as survey data, with its summits named. Move across it to read a grid reference and a height.

Arrow keys move the footprint, Shift moves it further, Home brings it back to the centre and Escape lets go.

GLEN COE · THREE SISTERS · SCOTLAND, rendered live in your browserHeights: Scottish Public Sector LiDAR, OGL v3 · Contains OS data © Crown copyright

Explore the system
SDR-002·Thesis

The hardest problems in climate and public safety are
no longer bound by what human crews can reach.

SIDRA builds autonomous aircraft for public agencies, researchers and industry. They fly where GPS fails and are held to aviation-grade standards. The platform that watches a forest also inspects a turbine: one autonomy stack, many missions.

The aircraft flies on its own estimate through denied navigation, geolocates what matters, and returns. The work begins where certainty ends.

The boundary is the beginning.

Fig. 01 · Glen Coe skylineMove along the ridge to read its heightDrag along the ridge to read its height
Glen Coe, the highest ground across the glen, north to southHeights: Scottish Public Sector LiDAR, OGL v3 · Contains OS data © Crown copyrightHighest point 1 137 m
SDR-006·Fleet

The fleet

One autonomy core, CUSTOS, flies every airframe, and every mission gets an airframe tuned to its envelope. A buildable quadcopter today, a hybrid VTOL in development, a long-endurance concept next.

Drag to turn the orbit, or pick an airframePick an airframe from the strip
Fig. 02 · NIGHTJARBUILDABLEDrag to orbit · buildable todayRender
NIGHTJAR from the engineering model, the rest concept geometry, rendered live. Seven airframes, one autonomy core.nightjar_build.glb
BUILDABLE

NIGHTJAR

Buildable today: ~£566 bill of materials, 37-minute hover target, flying the CUSTOS autonomy stack on commercial hardware.

Class7-INCH SURVEY QUADCOPTER
MissionWILDFIRE EARLY WARNING
293mmWHEELBASE
37minHOVERTarget
20kmRANGETarget
1.33kgAUWTarget

NIGHTJAR

BUILDABLE
7-INCH SURVEY QUADCOPTERWILDFIRE EARLY WARNING1.33 kg AUWTarget

Buildable today: ~£566 bill of materials, 37-minute hover target, flying the CUSTOS autonomy stack on commercial hardware.

WHEELBASE
293 mm
HOVER
37 minTarget
RANGE
20 kmTarget
AUW
1.33 kgTarget

UMBRA

IN DEVELOPMENT
HYBRID VTOLSEARCH & RESCUE2.8 m span

Bullet fuselage, blended wing, four lift rotors and a pusher: vertical launch anywhere, fixed-wing range once airborne. Designed to carry the ASTRUM SPAD low-light array (research) for after-dark sector sweeps.

SPAN
2.8 m
LENGTH
1.6 m
LIFT
4 × rotor + pusher
ENDURANCE
2.5 hTarget

BROCH

CONCEPT
LONG-ENDURANCE FIXED-WINGENVIRONMENTAL SURVEY · FLOOD8 h enduranceTarget

The watchtower of the fleet: an extended-range sensor platform for wide-area environmental survey, carbon verification and flood-corridor mapping.

SPAN
4.2 mTarget
ENDURANCE
8 hTarget
RANGE
400 kmTarget
PAYLOAD
4 kgTarget

CORVUS

PLANNED
QUIET HIGH-ORBIT MULTIROTORWILDLIFE PROTECTIONLow-noise props

Low-noise rotors and high-AGL optics for high orbits animals never notice.

ACOUSTIC
Low-noise props
OPTICS
EO zoom + IR
ORBIT
High AGL, wide

VENTUS

PLANNED
CLOSE-QUARTERS INSPECTION MULTIROTORENERGY ASSET INSPECTIONBlade-relative hold

Precision station-keeping against turbine blades and solar rows, macro imaging in ground-effect turbulence.

HOLD
Blade-relative
OPTICS
EO macro + thermal
ENVELOPE
Confined / turbulent

RAVN

PLANNED
BVLOS MARITIME PLATFORMOFFSHORE ASSETSGNSS-degraded capable

Salt-spray hardened BVLOS transit and structured survey where crewed flights stay grounded.

SEALING
IP-rated / marine
TRANSIT
BVLOS offshore
NAV
GNSS-degraded capable

FALKE

PLANNED
COASTAL SURVEY PLATFORMCOASTAL RESTORATIONTidal repeat lines

Low-tide repeat survey over mangrove restoration plots, multispectral scoring that steers the next seeding season.

OPTICS
Multispectral + EO
CADENCE
Tidal repeat lines
OUTPUT
Survival plot maps
SDR-005·Hardware
PRAETOR link · MAVLINK v2 · Sim feed · 10 Hz

NIGHTJAR, from the CAD

The exact airframe from the engineering model, wheelbase to fastener. Drag to orbit.

Fig. 03 · NIGHTJAR
Engineering model, rendered liveEngineering model
DRAG TO ORBIT
Specification
WHEELBASE293 mm
PROPULSION4 × 2806.5 · 7″ TRI-BLADE
ENERGY6S2P Li-ion · 181 Wh
FLIGHT COREH743 · ArduPilot
ALL-UP MASS1.33 kgTarget
THRUST/WEIGHT5.2:1
Live feed · simulation
PRAETOR linkMAVLink v2 · 10 Hz
Attituderoll +1.1° · pitch −1.6° · yaw 220.1°
Position56.6424 N · 4.9993 W · 25.1 m AGL
EstimatorEKF lock · σH 0.31 m
SDR-005B·Assembly
Parts 07

NIGHTJAR is designed down to the part number, on commercial hardware. Scroll to pull it apart.NIGHTJAR is designed down to the part number, on commercial hardware. Here it is, taken apart into its seven part groups.

Fig. 04 · Seven part groups
NIGHTJAR exploded into its seven part groups
Engineering model
  1. PROPULSION7″ TRI-BLADE · ×4
  2. CANOPYCARBON SHELL
  3. CUSTOSH743 FLIGHT COMPUTE
  4. MOTORS2807 · 6S · ×4
  5. SENSINGFPV · GPS · ELRS
  6. AIRFRAMESTRETCHED-X CARBON
  7. POWER6S2P LI-ION
SDR-004·Capability cores
CUSTOS · PRAETOR · IGNIS · ASTRUM

Four cores, one system.

CUSTOS flies it, PRAETOR commands it, IGNIS moves it, ASTRUM sees for it.

Fig. 05a · Four coresSimulatedEach core drawn as if it were running.Drawing
Control loopState estimate · EKF · 400 Hz

CUSTOS

IN DEVELOPMENT

Autonomy core for uncrewed platforms. Edge perception, on-board reasoning, and resilient flight across degraded and denied links. The guardian process every airframe runs.

The whole stack
CUSTOSIN DEVELOPMENT
CLASS
Autonomy / flight
DOMAIN
Air · Coastal
LINK
Degraded-tolerant
PRAETORIN DEVELOPMENT
CLASS
Ground control
SPAN
Multi-vehicle
AUTHORITY
Human-on-the-loop
IGNISCONCEPT
CLASS
Propulsion
CYCLE
Hybrid · ZE
TARGET
Endurance
ASTRUMRESEARCH
CLASS
Sensing / EO-IR
ARRAY
SPAD · multi-spectral
INFERENCE
Low-light · on-edge
Fig. 05b · GNSS deniedSimulatedThe CUSTOS estimate in LOG-014, June 2026: coasting a 20-second GNSS blackout.
Simulation, LOG-014, June 2026. Levels are the logged peaks, not a trace. Innovation gating drops one-off outliers; it does not protect against spoofing.
SDR-007·Civil operations
SimulatedWildfire detection and response

What the fleet is for

Every mission gets the aircraft it needs.

One autonomy core, CUSTOS, flies the whole fleet. Each mission is served by an airframe tuned to its envelope. The orbit that refines a wildfire fix also inspects a turbine blade. The platform differs. The discipline does not.

Fig. 06 · Survey of the glenSimulatedSeven missions simulated, one autonomy coreSurvey dataLIDAR · OS

The patrol walks all seven. Pick one to hold it.

Profile · CIV-01Standby
Alert--
Drops--
Fire--
Leg00/05
Grid--
Light--

Mission register

Seven planned missions, CIV-01 to CIV-07
SDR-014B·Europe fire watch
Feed

The gap between ignition and alert

Record · 2025 and 2026 seasons · verified October 2026

Detection still depends on watchtowers, passers-by and satellites that revisit hours apart. The gap between ignition and alert is where a one-crew fire becomes a thousand-hectare one, and it is the gap NIGHTJAR is built to patrol. 2025 was the UK’s worst fire season on record: eleven thousand hectares went at Carrbridge and Dava, the largest wildfire the country has recorded. A year on, in July 2026, the Cairngorms National Park was evacuated as fire spread north from Glenmore through forestry, and Arthur’s Seat burned in the heart of Edinburgh. Across the continent that July, Spain, Portugal, France, Greece, Italy and Türkiye burned through the third heatwave in six weeks. The scars on this board are that record, each one carrying its date. The thermal markers are whatever is open today.

11,000+ haBurned at Carrbridge & Dava · northern Scotland · June–July 2025 · the UK’s largest recorded wildfire (BBC)
16 JulyCairngorms National Park evacuated as fire spread north from Glenmore · 2026 (BBC)
505,000+ haBurned in the EU · 1 January to 5 August 2026 · ahead of the record 2025 season at the same date (EFFIS)
14+Lives lost · Europe · July 2026
Fig. 07a · EuropeSimulated patrol
Point at a fire, or pick a contact, to hold the patrol thereTap a fire or a contact to hold the patrol there
06 Reported ignition areas, July 2026 03 Burn scars, Scotland 2025 and 2026Base, GlasgowNIGHTJAR, simulated patrol
Record · 03 burn scarsBurned
Arthur's Seat · Edinburgh2026-07-19
Glenmore · Cairngorms2026-07-15
Carrbridge & Dava · Cairngorms2025-06-28
On station · thermal scanNIGHTJAR Pyrénées-Orientales42.60°N 2.60°E · Ground 565 m · 1 230 m of relief within 10 kmLogged · contact 1 of 6
10 kmConcept
48 km around the contact · contours every 50 m · nest catchments of 12,500 ha
Nearest nest 3.0 km off · on scene in 3.6 min at cruise
Contact · July 2026ReliefDistance

Relief is the rise from the lowest to the highest ground within 10 km of each contact, from the AWS Terrain Tiles (SRTM and Copernicus EU-DEM).

Distance is from the nearest nest. The nests are a concept.

Fig. 07b · The gapModel

What the gap costs

A free-burning fire grows with the SQUARE of the time it is left alone. Answer in seventeen seconds and it is a fifth of a square metre of ground. Answer when the next satellite pass has been processed and it is 403,599 times the fire.

Burned area against time since ignition, on a logarithmic time axis and a linear area axis, with the moment each kind of alert arrives marked on the curve.

NIGHTJARIgnition to alert in the engineering simulator, patrolling the ground it is over.

SATELLITENASA FIRMS publishes near-real-time detections about three hours after the satellite overpass that saw them.

In serviceexci 60 s · Türkiye OGM 2 min · Dryad 3 min · IQ FireWatch 6 min Between the two sit the systems already in service, in this order: exci camera AI on a slope, Türkiye's national forest-fire detection average, Dryad sensor mesh with its own drone, and IQ FireWatch towers. Vendor and operator figures, not ours. They are the comparison a buyer actually makes, and the reason the honest claim here is minutes saved on the field, not hours saved on a satellite.

Elliptical spread at 3 m/min, length-to-breadth 3:1. A model, not a measurement: real fires meet rivers, roads, rain and crews.

NIGHTJAR’s target: ignition to geolocated alert in under 90 seconds, on autonomous dawn and dusk patrol.

Watch it find the fire
SDR-009·Simulated mission · NIGHTJAR
Simulated · Patrol
Fig. 08 · Thermal patrolSimulation running

Watch it find the fire.

An autonomous patrol, simulated in your browser. Ignitions start at random. The thermal footprint sweeps them up, confirms, geolocates and orbits, the same logic that reached alert in 0.4 to 17 seconds from ignition in the engineering simulator, against a target of under 90 seconds on patrol.

or click the groundor tap the ground
ModePatrol
Confirmed00
Best–
Grid refNE 018-020
Ignition to alert, this run
Awaiting first ignition–––––

SDR-014·Live ops
Feed · EONETAcquiring

What each airframe would answer

Open natural events from NASA’s Earth Observatory (EONET), streamed onto the operations globe and routed to the airframe designed for that intervention. A live wildfire would task NIGHTJAR. A flooding river would task BROCH. No aircraft is dispatched from this page. Select an event to see the pairing.

Fig. 09 · Operations globeAcquiring
Drag to turn. Hold ⌘ and scroll to zoom.Tap an event. Inspect to turn and pinch.
Operations globe
Feed · EONETAcquiring
open events–
Routed– / 05
last sync–
Events · select one

Acquiring

Tasking

No event selected. The pairing shows which airframe answers which crisis.

Acquiring the feed. Until a pass lands the list stays empty. The NIGHTJAR track is illustrative.

RoutedOpen events, by the airframe each one tasks
NIGHTJAR00thermal patrol · ignition confirmWildfire
BROCH00corridor mapping · flood extentSevere storm · Flood · Drought · Dust and haze
UMBRA00search and rescue support · sector sweepEarthquake · Landslide · Snow
RAVN00BVLOS wide-area surveyVolcano · Man-made
FALKE00coastal survey · repeat baselinesSea ice · Water anomaly

Event data: NASA EONET (public domain). Tasking pairings illustrate fleet mission fit. No aircraft is dispatched from this page.

SDR-020·The nest
Phase 05 / 06 · Unfold

The aircraft should already be there.

Everything here is about the minutes between ignition and alert, and most of those minutes are spent driving to a trailhead. CAIRN is a sealed nest that sits on the hill through the winter and launches on a trigger.

Render
Fig. 10 · CAIRNConcept study
SDR-020Unfold

CAIRN is a concept study. Nothing here has been built or flown, and the model is a procedural sketch of the sequence rather than a render of hardware.

Drag to turn the model
DEPLOYMENT SEQUENCE
CONCEPT TARGETS
RESPONSETrigger to wheels-up, target under 90 s
SHELL900 × 900 × 520 mm, IP-rated, heated
WING2.4 m span, two-stage fold, 0.86 m stowed
UNIT OF SALEA catchment, not a flight
SDR-011·Team

Founder-led, from the airframe up.

Recruiting technical leads across the capability pillars.

LOG-000 · HERITAGEARATINGA

Loiter, manoeuvre, return: before it was code

Before any of this was an autonomy stack, there was a sun conure on the Red Sea shore at Suez. It would launch, work its own arcs over the water, and come back to hand: loiter, manoeuvre, return, flown on instinct. SIDRA is that instinct, engineered. Callsign: ARATINGA.

Fig. 11 · Aratinga
240 fps, 0.44 s of flight · legs illustrative
SDR-022·Airworthiness and assurance

Certified is a process, so we show the process.

Every behaviour claimed on this page traces to a check that runs in the repository, and the operating programme is being built against the UK framework from the first flight.

FLIGHT SAFETY CASE
The failsafes, GNSS denial, estimator steps and the return home, are exercised as automated tests across a sweep of randomised seeds, with the margins written next to the assertions they bound. A tuning that only works once cannot ship.
AUTOMATED CHECK
UK CAA OPERATIONS
Operator and flyer registration before the first flight, and the Open Category for close-quarters inspection. For BVLOS survey lines and an unattended nest the route is UK SORA at SAIL II, a route the CAA has already granted to other BVLOS operators (Network Rail, May 2026).
ROUTE CHOSEN
NAVIGATION INTEGRITY
The estimator carries its own integrity monitor: innovation gating rejects a fix that jumps, and the aircraft flies on its own estimate through a denied window rather than holding position and hoping.
AUTOMATED CHECK
DATA HANDLING
Survey imagery is collected for the mission, minimised at the edge and handled under UK GDPR, with an impact assessment before any hosted service ships. The land manager keeps the dataset; what we sell is the survey.
DESIGN RULE

The statuses mean what they say.

AUTOMATED CHECK
is a validator in the repository test suite that fails the build when it fails.
ROUTE CHOSEN
is a regulatory path decided, not an authorisation held.
DESIGN RULE
is a commitment in the design, not a certified control.
SDR-012·For investors
Ready

Building the layer between ignition and response.

SIDRA is an early-stage venture out of Glasgow, taking one autonomy core, CUSTOS, from validation in simulation toward first flight and operational deployment across wildfire early warning, inspection and environmental missions. We are in conversation with investors and partners who back frontier hardware and climate resilience.

Request the investor brief
SDR-013·Contact
Ready

Get in touch

LOCATIONGlasgow · Scotland
REGISTEREDScotland · Est. 2026
